Output

Power

额定Power

360W

720W

1080W

360W

720W

1080W

Power限制

约额定Power *105%

Voltage

额定Voltage

0-30V

0-30V

0-30V

0-80V

0-80V

0-80V

Voltage

31.5V

84V

Current

额定Current

0-33A

0-66A

0-100A

0-12.5A

0-25A

0-37.5A

Current

36A

72A

108A

13.5A

27A

40.5A

Suppose

ce

Voltage

The scope of

0-31.5V

0~84V

Current

The scope of

0~36A

0-72A

0-108A

0-13.5A

0-27A

0-40.5A

Load adjustment rate

Voltage

≤ 20mV

≤ 45mV

Current

≤ 41mA

≤ 77mA

≤ 113mA

≤ 18.5mA

≤ 32mA

≤ 45.5mA

Power regulation rate

Voltage

≤ 18mV

≤ 43mV

Current

≤ 41mA

≤ 77mA

≤ 113mA

≤ 18.5mA

≤ 32mA

≤ 45.5mA

Suppose定值解析度

Voltage

10mV

Current

10mA

10mA

100mA

10mA

10mA

10mA

Read back value resolution

Voltage

10mV

Current

10mA

10mA

100mA

10mA

10mA

10mA

Suppose定值Precision

(25 ℃± 5 ℃ )

Voltage (>0.1V)

≤ 0.1%+10mV

Current (>0.1A)

≤ 0.1%+30mA

≤ 0.1%+60mA

≤ 0.1%+100mA

≤ 0.1%+20mA

≤ 0.1%+40mA

≤ 0.1%+50mA

Precision of read back value

(25 ℃± 5 ℃ )

Voltage (>0.1V)

≤ 0.1%+20mV

Current (>0.1A)

≤ 0.1%+40mA

≤ 0.1%+70mA

≤ 0.1%+100mA

≤ 0.1%+20mA

≤ 0.1%+40mA

≤ 0.1%+50mA

Ripple and noise

(20Hz-2MHz)

差模Voltage

≤ 60mVp-p and 7mVrms

≤ 80mVp-p and 11mVrms

≤ 100mVp-p and 14mVrms

≤ 60mVp-p and

7mVrms

≤ 80mVp-p and

11mVrms

≤ 100mVp-p and 14mVrms

差模Current

≤ 72mArms

≤ 144mArms

≤ 216mArms

≤ 27mArms

≤ 54mArms

≤ 81mArms

Dynamic recovery time

(50%- Load )

Frequency =100Hz

Restore to 0.1% + 10mV: ≤ 2ms

Rise time (no load)

10%-90%

≤ 50ms

Rise time (full load)

10%-90%

≤ 50ms

Descent time (full load)

90%-10%

≤ 50ms

Descent time (no load)

90%-10%

≤ 500ms

Timer

SupposeceThe scope of

0-9999999 (every minute of the day)

Startup delay

SupposeceThe scope of

0-99.99s

Stop the delay

SupposeceThe scope of

0-99.99s

斜率Supposece

Voltage上升

0.01-60V/s

0.1-160V/s

Voltage下降

0.01-60V/s

0.1-160V/s

Current上升

0.01-72A/s

0.1-144A/s

0.1-216A/s

0.01-27A/s

0.01-54A/s

0.01-81A/s

Current下降

0.01-72A/s

0.1-144A/s

0.1-216A/s

0.01-27A/s

0.01-54A/s

0.01-81A/s

Simulated internal resistance

SupposeceThe scope of

0-0.833Ω

0-0.417Ω

0-0.278Ω

0-5.926Ω

0-2.963Ω

0-1.975Ω

外部Voltage控制

(25 ℃ ±5 ℃ )

CV Precision

额定OutputVoltage ±0.5%

CC Precision

额定OutputCurrent ±1%

External resistance control

(25 ℃ ±5 ℃ )

CV Precision

额定OutputVoltage ±1.5%

CC Precision

额定OutputCurrent ±1.5%

Power因数

100VAC A full load of

0.99

200VAC A full load of

0.97

Efficiency

100VAC A full load of

75%

76%

200VAC A full load of

77%

78%

Master-slave control

Master-slave parallel

At most, the host is connected in parallel 3 Taiwan

Master-slave series

With host at most series 2 Taiwan

Protect

Overvoltage OVP

3-33V

3-33V

3-33V

8-88V

8-88V

8-88V

overcurrent OCP

3.6-37.8A

5-75.6A

5-113.4A

1.35-14.18A

2.7-28.35A

4.05-42.53A

overtemperature OTP

Internal temperature rise determines

Volume and weight

External volume ( mm ）

215(W)×146(H)×420(D)

Shelf volume ( mm ）

215(W)×132(H)×420(D)

Weight (net weight)

3kg

5.3kg

7.5kg

3kg

5.3kg

7.5kg

Power supply Power

88-265VAC , 50/60HZ

Note:

l Power regulation rate（ 88-132VAC Or 170-265VAC Dead load)

l Load调解率（空载 - 满载,恒输入Voltage）

l 上升时间（额定OutputVoltage 10%-90% ,带额定电阻Load）

l 下降时间（额定OutputVoltage 90%-10% ,带额定电阻Load）

l Dynamic recovery time（Load从额定OutputCurrent的 50% To 变化时,OutputVoltage在额定Output的 0.1%+10mV The scope of内恢复的时间）
