Product Description:
JK2515B-4D multichannel resistance tester is a kind of high precision wide range, high speed, using high-performance microprocessor control internal using embedded resistance tester Resistance tester designed for industrial control,
Custom ranges, from 10μΩ to 20 kω, benefit from Jinailian's cutting-edge resistance measurement technology, enabling test speeds Up to 20 beats per second. JK2515B-4D is the smallest resistance tester to date, internal independent 4 groups of
Resistance tester, upper and lower limit setting, with PLC trigger interface PASS/FAIL output
JK2515B-4DResistance tester designed for industrial control,定制The range of,从10μΩ～20kΩ是迄今小型的电阻测试仪,内部为独立4 groups of电阻测试仪,上下极限设置,
Have PLC trigger interface PASS/FAIL output.
Product Features:
1. Test speed up to 20 times/second
2. High precision and wide range. Especially suitable for small resistance test
3. Strong anti-interference, stable data
4. Resistance values of 4 different ranges can be tested at the same time
5 range, current visual disy, direct selection.
6. 4 internal independent equivalent to 4 sets of low resistance tester
Product application:
▶ Measurement of various high, medium and low value resistors
▶ Contact resistance of various switches
▶ Enamelled wire resistance
▶ Connector contact resistance
▶ Relay wire package and contact resistance
▶ Transformer, inductor, motor, deflection coil winding resistance
▶ Solder joint contact resistance
▶ Conductor resistance
▶ Metal riveting resistors for cars, ships, and aircraft
▶ Printed te lines and perforated resistors
▶ Characterizing the low resistance characteristics of electromechanical components
▶ Metal inspection, etc
Technical specifications:
Model number |
JK2515B-4D |
|
Multiplex test |
Any combination of paths |
|
Overall dimensions |
350 mm(W) x340 mm(D) x110 (H) |
|
Basic accuracy |
0.1% |
|
The range of |
10μΩ ～ 20kΩ |
|
Show |
3999 Reading |
|
High speed test |
20 times per second |
|
Correction function |
Short circuit zero clearing function |
|
Comparator (sorting) function |
内置比较器,PASS/FAIL分选结果Show和IO输出 |
|
Interface |
内置HandlerInterface.RS232Interface |
|
Test end |
Four-terminal test |
|
